Lenze · i700 servo inverter · reference manual · DMS 3.0 EN · 06/2016 · TD06 78
5 Motor control & motor settings
5.7 Compensating for inverter influence on output voltage
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Loading the standard inverter characteristic
If an incorrect inverter characteristic has been determined or none at all, it is possible to load a
device-typical standard inverter characteristic.
 How to load the standard inverter characteristic:
1. Set object 0x2822
(or 0x3022 for axis B) to "1".
• The progress of the procedure is shown in object 0x2823
(or 0x3023 for axis B).
2. For permanent storage: After completion of the procedure, upload the inverter
characteristic set in 0x2947
(or 0x3147 for axis B) to the controller from the i700 servo
inverter.
The »EASY Starter« serves to save the parameter settings of the i700 servo inverter as
parameter file (*.gdc). In the »PLC Designer«, this file can then be imported in the
corresponding axis. Saving changed parameters safe against mains failure
( 53)
0x2947 | 0x3147 - Inverter characteristic: Voltage grid points (y)
Subindex 5: Torque: 4 or 16 kHz interpolation
Selection list (Lenze setting printed in bold)
0Off
1On
 Write access  CINH  OSC  P  RX  TX UNSIGNED_8
y values of the 17 grid points of the inverter characteristic
Sub. Name Lenze setting Data type
1 IC: y1 = U01 (x = 0.00 %) 0.00 V UNSIGNED_16
2 IC: y2 = U02 (x = 6.25 %) 0.00 V UNSIGNED_16
3 IC: y3 = U03 (x = 12.50 %) 0.00 V UNSIGNED_16
4 IC: y4 = U04 (x = 18.75 %) 0.00 V UNSIGNED_16
5 IC: y5 = U05 (x = 25.00 %) 0.00 V UNSIGNED_16
6 IC: y6 = U06 (x = 31.25 %) 0.00 V UNSIGNED_16
7 IC: y7 = U07 (x = 37.50 %) 0.00 V UNSIGNED_16
8 IC: y8 = U08 (x = 42.75 %) 0.00 V UNSIGNED_16
9 IC: y9 = U09 (x = 50.00 %) 0.00 V UNSIGNED_16
10 IC: y10 = U10 (x = 56.25 %) 0.00 V UNSIGNED_16
11 IC: y11 = U11 (x = 62.50 %) 0.00 V UNSIGNED_16
12 IC: y12 = U12 (x = 68.75 %) 0.00 V UNSIGNED_16
13 IC: y13 = U13 (x = 75.00 %) 0.00 V UNSIGNED_16
14 IC: y14 = U14 (x = 81.25 %) 0.00 V UNSIGNED_16
15 IC: y15 = U15 (x = 87.50 %) 0.00 V UNSIGNED_16
16 IC: y16 = U16 (x = 93.25 %) 0.00 V UNSIGNED_16
17 IC: y17 = U17 (x = 100.00 %) 0.00 V UNSIGNED_16
 Write access  CINH  OSC  P  RX  TX
