Lenze i700 User Manual

5 Motor control & motor settings
5.8 Setting the motor parameters for the servo control
85
Lenze · i700 servo inverter · reference manual · DMS 3.0 EN · 06/2016 · TD06
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.8.3 Motor parameters (object descriptions)
0x2C01 | 0x3401 - Motor: Common parameters
 Note!
In the objects 0x2C01 and 0x2C02, parameters of a motor in star connection are
described. If you want to use a motor in delta connection, the data of a winding (e.g.
from the associated data sheet of the motor) has to be converted into the equivalent
values of the star connection.
The stator resistance (object 0x2C01:2
or 0x34E0:2 for axis B) for the motor in delta
connection, for instance, is calculated as follows:
R
delta connection
1
3
---
R
star connection
⋅=
Sub. Name Lenze setting Data type
1 Motor: Number of pole pairs UNSIGNED_8
2 Motor: Stator resistance 13.5000 ohms UNSIGNED_32
3 Motor: Stator leakage inductance 51.000 mH UNSIGNED_32
4 Motor: Rated speed 4050 rpm UNSIGNED_16
5 Motor: Rated frequency 270.0 Hz UNSIGNED_16
6 Motor: Rated power 0.25 kW UNSIGNED_16
7 Motor: Rated voltage 225 V UNSIGNED_16
8 Motor: Rated cosine phi 0.80 UNSIGNED_16
9 Motor: Insulation class 4: F (cut-off temperature = 155 °C) UNSIGNED_8
10 Motor: Designation STRING(50)
Subindex 1: Motor: Number of pole pairs
Display area (min. value | unit | max. value) Initialisation
0 255
 Write access  CINH  OSC  P  RX  TX UNSIGNED_8
Subindex 2: Motor: Stator resistance
see also motor equivalent circuit
Stator resistance of a motor phase (reference: ϑ = 20 °C)
Setting range (min. value | unit | max. value) Lenze setting
0.0000 Ohm 125.0000 13.5000 ohms
 Write access  CINH  OSC  P  RX  TX Scaling: 1/10000 UNSIGNED_32
Subindex 3: Motor: Stator leakage inductance
see also motor equivalent circuit
Stator leakage inductance (ASM) or leakage inductance (SM) of a motor phase
Setting range (min. value | unit | max. value) Lenze setting
0.000 mH 500.000 51.000 mH
 Write access  CINH  OSC  P  RX  TX Scaling: 1/1000 UNSIGNED_32

Lenze i700 Specifications

General

Control Type	Vector control, V/f control
Safety	STO (Safe Torque Off)
Protection Class	IP20
Frequency	50/60 Hz
Communication Interfaces	CANopen
Cooling	Air cooled
Protection Features	Overvoltage, Undervoltage
Ambient Temperature	-10°C to +45°C
Frequency Range	0 Hz to 300 Hz
Supply Voltage	3-phase AC
