0x2DD7 | 0x35D7 - Voltage values
Subindex 1: Torque: filter cascade - starting value
Display area (min. value | unit | max. value) Initialisation
-3276.7 % 3276.7 0.0 %
 Write access  CINH  OSC  P  RX  TX Scaling: 1/10 INTEGER_16
Subindex 2: Torque: notch filter 1 - input value
Display area (min. value | unit | max. value) Initialisation
-3276.7 % 3276.7 0.0 %
 Write access  CINH  OSC  P  RX  TX Scaling: 1/10 INTEGER_16
Subindex 3: Torque: notch filter 2 - input value
Display area (min. value | unit | max. value) Initialisation
-3276.7 % 3276.7 0.0 %
 Write access  CINH  OSC  P  RX  TX Scaling: 1/10 INTEGER_16
Subindex 4: Torque: target torque filtered
Display area (min. value | unit | max. value) Initialisation
-3276.7 % 3276.7 0.0 %
 Write access  CINH  OSC  P  RX  TX Scaling: 1/10 INTEGER_16
Sub. Name Lenze setting Data type
1 Current motor voltage limit: Actual voltage INTEGER_16
2 D-current controller: Output signal INTEGER_16
3 Q-current controller: Output signal INTEGER_16
4 D-voltage (magnetisation) INTEGER_16
5 Q-voltage (torque) INTEGER_16
Subindex 1: Current motor voltage limit: actual voltage
Display area (min. value | unit | max. value) Initialisation
-3276.7 V 3276.7
 Write access  CINH  OSC  P  RX  TX Scaling: 1/10 INTEGER_16
Subindex 2: D-current controller: output signal
Display area (min. value | unit | max. value) Initialisation
-3276.7 V 3276.7
 Write access  CINH  OSC  P  RX  TX Scaling: 1/10 INTEGER_16
Subindex 3: Q-current controller: output signal
Display area (min. value | unit | max. value) Initialisation
-3276.7 V 3276.7
 Write access  CINH  OSC  P  RX  TX Scaling: 1/10 INTEGER_16
Subindex 4: D-voltage (magnetisation)
Display area (min. value | unit | max. value) Initialisation

Lenze i700 Specifications

General

Control Type	Vector control, V/f control
Safety	STO (Safe Torque Off)
Protection Class	IP20
Frequency	50/60 Hz
Communication Interfaces	CANopen
Cooling	Air cooled
Protection Features	Overvoltage, Undervoltage
Ambient Temperature	-10°C to +45°C
Frequency Range	0 Hz to 300 Hz
Supply Voltage	3-phase AC
