5.1.3 V/f characteristic control for asynchronous motor (ASM)
Required commissioning steps
1st Wiring check by means of manual test modes
2nd Setting the control mode
3rd Accepting/adapting plant parameters
4th Compensating for inverter influence on output voltage
5th Only required if voltage vector control, DC-injection braking, or flying restart process is activated:
Setting and optimising the current controller
6. Defining the V/f characteristic shape
7. Setting the voltage boost
8. Setting the load adjustment
9. Torque increase in the lower speed range ("Boost" function)
10. Defining the behaviour at the current limit (Imax controller)
Optional commissioning steps (additional function or fine adjustment)
A. "Flying restart" function
B. "DC-injection braking" function
C. Setting the slip compensation
D. Setting the oscillation damping
