Lenze i700 User Manual

10 Service/internal
303 Lenze · i700 servo inverter · reference manual · DMS 3.0 EN · 06/2016 · TD06
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
0x2DD2 | 0x35D2 - Position: Target position interpolated
0x2DD3 | 0x35D3 - Target speeds
Subindex 1: D current (id): Actual D-current
Display area (min. value | unit | max. value) Initialisation
-327.67 A 327.67
 Write access  CINH  OSC  P  RX  TX Scaling: 1/100 INTEGER_16
Subindex 2: Q current (iq): Actual Q-current
Display area (min. value | unit | max. value) Initialisation
-327.67 A 327.67
 Write access  CINH  OSC  P  RX  TX Scaling: 1/100 INTEGER_16
Subindex 3: D current (id): Target D current
Display area (min. value | unit | max. value) Initialisation
-327.67 A 327.67
 Write access  CINH  OSC  P  RX  TX Scaling: 1/100 INTEGER_16
Subindex 4: Q current (iq): Target Q current
Display area (min. value | unit | max. value) Initialisation
-327.67 A 327.67
 Write access  CINH  OSC  P  RX  TX Scaling: 1/100 INTEGER_16
Subindex 5: Motor current Ieff
Display area (min. value | unit | max. value) Initialisation
-327.67 A 327.67
 Write access  CINH  OSC  P  RX  TX Scaling: 1/100 INTEGER_16
Display area (min. value | unit | max. value) Initialisation
-2147483647 [Pos unit] 2147483647 0 [Pos unit]
 Write access  CINH  OSC  P  RX  TX INTEGER_32
Sub. Name Lenze setting Data type
1 Speed: Target speed 0rpm INTEGER_32
2 Speed: Target speed 2 0rpm INTEGER_32
3 Speed: Target speed limited 0rpm INTEGER_32
Subindex 1: Speed: target speed
Display area (min. value | unit | max. value) Initialisation
-480000 r/min 480000 0 rpm
 Write access  CINH  OSC  P  RX  TX INTEGER_32
Subindex 2: Speed: target speed 2
Display area (min. value | unit | max. value) Initialisation

Lenze i700 Specifications

General

Control Type	Vector control, V/f control
Safety	STO (Safe Torque Off)
Protection Class	IP20
Frequency	50/60 Hz
Communication Interfaces	CANopen
Cooling	Air cooled
Protection Features	Overvoltage, Undervoltage
Ambient Temperature	-10°C to +45°C
Frequency Range	0 Hz to 300 Hz
Supply Voltage	3-phase AC
