8 Monitoring functions
8.6 Motor speed monitoring
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
8.6 Motor speed monitoring
0x2D44 | 0x3544 - Motor speed monitoring
Sub. Name Lenze setting Data type
1 Motor speed monitoring: Threshold 8000 r/min UNSIGNED_16
2 Motor speed monitoring: Response 1: Trouble UNSIGNED_8
Subindex 1: Motor speed monitoring: Threshold
Warning/error threshold for motor speed monitoring
Setting range (min. value | unit | max. value) Lenze setting
50 r/min 50000 8000 r/min
 Write access  CINH  OSC  P  RX  TX UNSIGNED_16
Subindex 2: Motor speed monitoring: Response
Response when tripping the motor speed monitoring
Selection list (Lenze setting printed in bold)
0 No response
1Fault
2 Warning
 Write access  CINH  OSC  P  RX  TX UNSIGNED_8
