Lenze · i700 servo inverter · reference manual · DMS 3.0 EN · 06/2016 · TD06 38
3 Communication with the controller
3.6 Ethernet over EtherCAT (EoE)
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
3.6.4.3 Error codes
The error code is located in the User data area P0, byte 1 and byte 2.
Possible error codes
User data area P0
Byte 1 Byte 2 Byte 3 Byte 4
Error code Data type Reserved
Example error code 0x9002
Low byte High byte
0x02 0x90
 Note!
The other user data contents correspond to those of an error-free message.
Error code Definition Description
Decimal hex
33803 0x840B Invalid type Invalid parameter type
33804 0x840C Limit violation Invalid parameter value
33806 0x840E Unknown parameter Invalid parameter index
33812 0x8414 Invalid size Invalid parameter format
33813 0x8415 Not in select list Parameter is not in the selection list
33814 0x8416 Read not allowed Parameter read is not allowed
33815 0x8417 Write not allowed Parameter write is not allowed
33816 0x8418 CINH not set Controller inhibit is not set
33829 0x8425 Invalid subindex Invalid parameter subindex
33837 0x842D Access not allowed Parameter access not allowed
36873 0x9009 Wrong GMT received The general telegram identification does not correspond
to the GCI communication.
36874 0x900A Unknown server request Internal error in the GCI
36878 0x900E SRV timeout
