5 Motor control & motor settings
5.14 Parameterising the V/f characteristic control
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
 Tip!
For magnetising the motor, consider a sufficient time from the controller enable to the
start of the speed ramp function generator.
• The bigger the motor the longer the time required for magnetisation. A motor with a
power of 90 kW requires up to 2 seconds.
0x2B06 | 0x3306 - VFC: Voltage boost
5.14.4 Setting the load adjustment
0x2B07 | 0x3307 - VFC: Load adjustment parameter
Voltage boost
Setting range (min. value | unit | max. value) Lenze setting
0.0 V 100.0 0.0 V
 Write access  CINH  OSC  P  RX  TX Scaling: 1/10 UNSIGNED_16
 Stop!
If the load adjustment is too high, the motor current may increase in idle state and the
motor may overheat!
Sub. Name Lenze setting Data type
1 VFC: Load adjustment - direction of rotation 0: Passive load (e.g. friction) UNSIGNED_8
2 VFC: Load adjustment - value 20.00 % UNSIGNED_32
Subindex 1: VFC: Load adjustment - direction of rotation
Adaptation of the characteristic depending on the load in the case of CW and CCW rotation
Selection list (Lenze setting printed in bold) Info
0 Passive load (e.g. friction) The motor operates in motor mode in both directions.
1 Active load, CCW (e.g. hoist) Application example: Hoist without counterweight
2 Active load, CW (e.g. hoist) Application example: Dancer-controlled unwinder
 Write access  CINH  OSC  P  RX  TX UNSIGNED_8
Subindex 2: VFC: Load adjustment - value
Load adjustment in [%] proportionally to the rated torque, in order to obtain a correspondingly "rigid" drive
behaviour even after the starting action.
• When starting torque = rated torque, a load adjustment of 50 % is suitable for most applications.
Setting range (min. value | unit | max. value) Lenze setting
0.00 % 200.00 20.00 %
 Write access  CINH  OSC  P  RX  TX Scaling: 1/100 UNSIGNED_32
