5.8 Setting the motor parameters for the servo control

If the servo control (SM, ASM) is applied, it is required to parameterise the so-called motor model

first. These are electrical variables which are provided in the i700 servo inverter as parameters.

5.8.1 Lenze motor: Easy loading of motor data from the catalogue via the »PLC-Designer«

For Lenze motors with a standard feedback system installed by Lenze, the required motor

parameters are provided by the »PLC Designer« during the motor selection by means of catalogues

and automatically copied to the i700 servo inverter in the default setting.

In this case, you can directly go to the next commissioning step:

Setting the feedback system for the servo control

5.8.2 Motors of other manufacturers or no catalogue data available: Three possibilities to create

the setting

For motors of other manufacturers or if there are no catalogue data available for the motor, three

alternative possibilities for setting the motor parameters are provided:

A. Enter motor nameplate data

(and have motor model parameters determined automatically)

B. Set motor parameters manually

C. Determine motor parameters automatically via "motor parameter identification"

The following subchapters provide detailed information on the three alternative methods. The

Engineering tool saves the used method to the following object so that the suitable

parameterisation dialogs are available the next time an online connection is present.

0x2C08 | 0x3408 - motor: Setting method - motor parameters

Selection list (Lenze setting printed in bold) Info

1 Select from catalogue (Lenze motor) For Lenze motors with a standard feedback system

installed by Lenze, the required motor parameters are

provided by the »PLC Designer« during the motor

selection by means of catalogues and automatically

copied to the i700 servo inverter in the default setting.

2 Enter motor nameplate data (other motors) Enter motor nameplate data

(and have motor model parameters determined

automatically)

3 Manually (other motors) Set motor parameters manually

4 Identification in progress (all motors) Determine motor parameters automatically via

"motor parameter identification"

 Write access  CINH  OSC  P  RX  TX UNSIGNED_8
