Lenze · i700 servo inverter · reference manual · DMS 3.0 EN · 06/2016 · TD06 261

8 Monitoring functions

8.4 Monitoring of the motor utilisation (I²xt)

_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _

0x2D4D | 0x354D - Motor utilisation (I²xt): User-definable characteristic

An example of how to enter the characteristic can be found in the following subchapter.

Operating points

 Standstill n01-I01 For motors, this operating point is often described with

the no-Io values.

 Reference point n02-I02 If the value falls below the speed n02, a derating in the

current is required because:

• the motor cooling of self-ventilated motors

deteriorates considerably.

• a DC current load causes an increased power loss in a

winding.

For motors, this operating point is also described with

the no*-Io* values.

 Rated point (n03=nrated)-(I03=Irated) Rated values of the motor are the reference for all

operating points of the i²xt monitoring.

 Field weakening n04-I04 This operating point should be parameterised

independently of the use in the current application.

Sub. Name Lenze setting Data type

1 I²xt: x1 = n01/nN (n01 ~ 0) 0 % UNSIGNED_16

2 I²xt: y1 = i01/iN (x = n01 ~ 0) 100 % UNSIGNED_16

3 I²xt: x2 = n02/nN (n02 = limit - reduced cooling) 0 % UNSIGNED_16

4 I²xt: y2 = i02/iN (x = n02 = limit - reduced

cooling)

100 % UNSIGNED_16

5 I²xt: x3 = n03/nN (n03 = rated speed) 100 % UNSIGNED_16

6 I²xt: y3 = i03/iN (x = n03 = rated speed) 100 % UNSIGNED_16

7 I²xt: x4 = n04/nN (n04 = limit - field weakening) 100 % UNSIGNED_16

8 I²xt: y4 = i04/iN (x = n04 = limit - field

weakening)

100 % UNSIGNED_16

 Write access  CINH  OSC  P  RX  TX
