R&S ESR Series User Manual

Remote Control
R&S
®
ESR
1041User Manual 1175.7068.02 ─ 12
●
When you switch between remote control languages, the following settings or
changes are made:
SCPI:
The instrument performs a PRESET.
8566A/B, 8568A/B, 8594E; FSEA, FSEB, FSEM; FSEK:
– The instrument performs a PRESET.
– The following instrument settings are changed:
Table 11-31: Instrument settings for emulation of 8566A/B, 8568A/B, 8594E; FSEA, FSEB, FSEM;
FSEK instruments
Model # of Trace
Points
Start Freq. Stop Freq. Ref Level Input Coupling
8566A/B 1001 2 GHz 22 GHz 0 dBm AC
8568A/B 1001 0 Hz 1.5 GHz 0 dBm AC
8560E 601 0 Hz 2.9 GHz 0 dBm AC
8561E 601 0 Hz 6.5 GHz 0 dBm AC
8562E 601 0 Hz 13.2 GHz 0 dBm AC
8563E 601 0 Hz 26.5 GHz 0 dBm AC
8564E 601 0 Hz 40 GHz 0 dBm AC
8565E 601 0 Hz 50 GHz 0 dBm AC
8594E 401 0 Hz 3 GHz 0 dBm AC
Note: The stop frequency indicated in the table may be limited to the corresponding
frequency of the R&S ESR, if required.
11.18.2 Command Set of Models 8560E, 8561E, 8562E, 8563E, 8564E,
8565E, 8566A/B, 8568A/B, 8591E, 8594E, 71100C, 71200C, and
71209A
As with the original units, the R&S ESR includes the command set of the A models in
the command set of the B models.
The HP model 8591E is compatible to HP model 8594E, the HP models 71100C,
71200C, and 71209A are compatible to HP models 8566A/B.
Command Supported subset Function Corresp. HP-
Models
Status
A1 A1 Clear/Write A HP 8566A/
HP 8568A
available
A2 A2 Max Hold A HP 8566A/
HP 8568A
available
GPIB Commands of HP Models 856xE, 8566A/B, 8568A/B and 8594E
