R&S ESR Series User Manual

Remote Control
R&S
®
ESR
796User Manual 1175.7068.02 ─ 12
Parameters:
<State> ON | OFF
*RST: OFF
Example:
SWE:EGAT:TRAC1:STAT1 ON
Activates tracing for range 1 of trace 1.
Manual operation: See "Gate Ranges" on page 320
[SENSe:]SWEep:EGATe:TRACe<k>: STOP<range> <Value>
This command defines the stopping point for the range to be traced using gated trig-
gering
Suffix:
<k>
.
1...6
trace
<range> 1...3
range
Parameters:
<Value> <numeric value>
*RST: 1 μs
Example:
SWE:EGAT:TRAC1:STOP1 5ms
Sets the stopping point for range 1 on trace 1 at 5 ms.
Manual operation: See "Gate Ranges" on page 320
Scaling the Diagram
The following commands configure the diagram for statistical measurements.
CALCulate<n>:STATistics:PRESet...................................................................................796
CALCulate<n>:STATistics:SCALe:AUTO ONCE................................................................797
CALCulate<n>:STATistics:SCALe:X:RANGe.....................................................................797
CALCulate<n>:STATistics:SCALe:X:RLEVel..................................................................... 798
CALCulate<n>:STATistics:SCALe:Y:LOWer......................................................................798
CALCulate<n>:STATistics:SCALe:Y:UNIT.........................................................................798
CALCulate<n>:STATistics:SCALe:Y:UPPer.......................................................................799
CALCulate<n>:STATistics:PRESet
This command resets the scaling of the X and Y axes in a statistical measurement.
The following values are set:
x-axis ref level: -20 dBm
x-axis range APD: 100 dB
x-axis range CCDF: 20 dB
Remote Commands in Spectrum Analyzer Mode
