R&S ESR Series User Manual

Quick Start
R&S
®
ESR
80User Manual 1175.7068.02 ─ 12
Key name
(upper inscription)
Series of (special) characters and number provided
4 G H I 4
5 J K L 5
6 M N O 6 Ň Ö
1 P Q R S 1
2 T U V 2 Ü
3 W X Y Z 3
0 <blank> 0 – @ + / \ < > = % &
. . * : _ , ; " ' ? ( ) #
– <toggles between capital and small letters>
3.4.3.3 Navigating in Dialog Boxes
Some of the dialog boxes are not only for parameter entry, and therefore have a more
complex structure. The following figure shows an example.
Changing the focus
The focus on the graphical user interface is moved by pressing an element on the
screen, or via the rotary knob. The focused area is marked with a blue frame (see Fig-
ure 3-6). If this area consists of more than one element, e.g. lists of options or tables,
Basic Operations
