R&S ESR Series User Manual

Remote Control
R&S
®
ESR
771User Manual 1175.7068.02 ─ 12
Example:
ESP:RANG1:TRAN 'test'
Sets the transducer called test for range 1.
Manual operation: See "Transd. Factor" on page 260
Configuring the Reference Range
The following commands define the reference range for the SEM sweep list.
[SENSe:]ESPectrum:BWID............................................................................................. 771
[SENSe:]ESPectrum:FILTer[:RRC]:ALPHa........................................................................771
[SENSe:]ESPectrum:FILTer[:RRC][:STATe]....................................................................... 772
[SENSe:]ESPectrum:RRANge.........................................................................................772
[SENSe:]ESPectrum:RTYPe........................................................................................... 772
[SENSe:]ESPectrum:BWID <Bandwidth>
This command defines the bandwidth used for measuring the channel power (refer-
ence range). This setting takes only effect if channel power is selected as power refer-
ence type (see [SENSe:]ESPectrum:RTYPe on page 772).
Parameters:
<Bandwidth> minimum span ≤ value ≤ span of reference range
*RST: 3.84 MHz
Example:
ESP:RTYP CPOW
Sets the power reference type to channel power.
ESP:BWID 1 MHZ
Sets the Tx bandwidth to 1 MHz.
Manual operation: See "Edit Reference Range" on page 263
[SENSe:]ESPectrum:FILTer[:RRC]:ALPHa <Value>
This command sets the alpha value of the RRC filter. This setting takes only effect if
channel power is selected as power reference type ( [SENSe:]ESPectrum:RTYPe
command) and if the RRC filter is activated ( [SENSe:]ESPectrum:FILTer[:
RRC][:STATe]command).
Parameters:
<Value> 0 to 1
*RST: 0.22
Example:
ESP:RTYP CPOW
Sets the power reference type to channel power.
ESP:FILT ON
Activates the use of an RRC filter.
ESP:FILT:ALPH 0.5
Sets the alpha value of the RRC filter to 0.5.
Manual operation: See "Edit Reference Range" on page 263
Remote Commands in Spectrum Analyzer Mode
