Receiver Mode
R&S
®
ESR
215User Manual 1175.7068.02 ─ 12
time range representation, negative times may also be entered. The allowed range
is -1000 s to +1000 s.
5.4.3.4 Working with Lines
If a line is switched on, the softkey is highlighted.
Switching a line on or off
1. Press the Display Lines softkey.
2. Press the softkey for the required line, e.g. Display Line 1 / Display Line 2.
An edit dialog box is opened to enter the position of the line. If the line was
switched off, it is switched on. If it was switched on, it remains switched on.
3. If another softkey is pressed, the edit dialog box for the line is closed, but the line
remains switched on (softkey with highlighted background).
4. When you press the Display Line 1 / Display Line 2 softkey for the second time, the
edit dialog box for the line is opened again.
5. When you press the Display Line 1 / Display Line 2 softkey the third time, the line
is switched off (softkey without highlighted background).
5.4.3.5 Selecting a Limit Line
●
To display the "Select Limit Line" dialog box, press the LINES key.
All limit lines saved in the default directory and all subdirectories are displayed. For
each limit line, the following information is given:
"Unit" unit of the y-axis
"Traces" selected traces to check
"Show" limit line displayed in the measurement diagram or hidden
"Compatible" compatibility of the limit line to the current measurement settings
"Offset" user-definable X- and Y-offset for the limit line
Common Analysis Functions
