R&S ESR Series User Manual

Tracking Generator
R&S
®
ESR
476User Manual 1175.7068.02 ─ 12
8 Tracking Generator
Equipped with option R&S FSV-B9, an internal tracking generator emits a signal at the
exact input frequency of the analyzer during operation. The generated signal is sent to
the DUT, thus allowing the analyzer to control the input frequency of the device directly.
When you equip the R&S ESR with option R&S FSV-B10, you are also able to control
various commercially available generators as a tracking generator.
Tracking generator control is available in "Spectrum" and "I/Q Analyzer" mode for fre-
quency, time or I/Q measurements. Special measurement functions are not available
with tracking generator control. The corresponding softkeys in the "Measurement"
menu are deactivated in this case.
Menu and softkey description
●
Chapter 8.1, "Softkeys of the Tracking Generator Menu", on page 476
Further information
8.1 Softkeys of the Tracking Generator Menu
The "Tracking Generator" menu is displayed when you press the INPUT/OUPUT key
and then "Tracking Generator".
This softkey is only available if the R&S FSV option Tracking Generator (B9) or Exter-
nal Tracking Generator (B10) or both are installed. The following table shows all soft-
keys available in the "Tracking Generator" menu.
As long as a tracking generator is active, the HOME key also displays the "Tracking
Generator" menu.
Source RF Internal (On/ Off).......................................................................................477
Source Power..............................................................................................................477
Source Cal.................................................................................................................. 477
└ Calibrate Transmission................................................................................. 477
└ Calibrate Reflection Short.............................................................................477
└ Calibrate Reflection Open.............................................................................477
└ Normalize......................................................................................................478
└ Reference Value Position..............................................................................478
└ Reference Value........................................................................................... 478
└ Recall............................................................................................................478
└ Save As Trd Factor....................................................................................... 479
Modulation...................................................................................................................479
└ External AM.................................................................................................. 479
└ External FM...................................................................................................479
└ External I/Q...................................................................................................479
└ Modulation OFF............................................................................................ 479
Softkeys of the Tracking Generator Menu
