Remote Control

R&S

ESR

1065User Manual 1175.7068.02 ─ 12

Command Supported subset Function Corresp. HP-

Models

Status

VTL VTL <numeric_value>

DB|DM

VTL DN

VTL UP

VTL?

Video Trigger Level HP 856xE/

HP 8594E

not available

1) HP 8594E only

2) Command is accepted without error message, but is ignored

11.18.3 Special Features of the Syntax Parsing Algorithms for 8566A and

8568A Models

The command syntax is very different for models A and B. Different names are

assigned to identical instrument functions, and the command structure likewise differs

considerably between models A and models B.

The command structure for models A is as follows:

<command>::= <command

code>[<SPC>][<data>|<step>][<SPC>][<delimiter>][<command

code>]…<delimiter>

<data>::= <Value>[<SPC>][<units

code>][<SPC>][<delimiter>][<SPC>][<data>]…

<step>::= UP|DN

where

<command code> = see Table "Supported Commands"

<Value> = integer or floating-point numerical value

<units code> = DM | -DM | DB | HZ | KZ | MZ | GZ | MV | UV | SC | MS | US

<SPC> = 32

<ETX> = 3

Command sections given in [ ] are optional.

The R&S ESR GPIB hardware differs from that used in the HP analyzers. Therefore,

the following constraint exists:

<LF>| <EOI> are still used as delimiters since the GPIB hardware is able to identify

them. The other delimiters are identified and evaluated during syntax analysis.

GPIB Commands of HP Models 856xE, 8566A/B, 8568A/B and 8594E
