11.5.3 Analyzing Spectrum Measurements
● Trace Configuration...............................................................................................847
● Spectrogram..........................................................................................................856
● Limit Lines.............................................................................................................860
● Markers................................................................................................................. 861
11.5.3.1 Trace Configuration
Commands to configure trace described elsewhere:
●
DISPlay[:WINDow<n>]:TRACe<t>:MODE on page 683
Commands exclusive in spectrum mode
CALCulate<n>:MATH[:EXPression][:DEFine].................................................................... 847
CALCulate<n>:MATH:MODE...........................................................................................848
CALCulate<n>:MATH:POSition....................................................................................... 848
CALCulate<n>:MATH:STATe........................................................................................... 848
DISPlay[:WINDow<n>]:TRACe<t>:MODE:HCONtinuous....................................................849
DISPlay[:WINDow<n>]:TRACe<t>[:STATe]....................................................................... 849
FORMat[:DATA]............................................................................................................. 850
FORMat:DEXPort:DSEParator........................................................................................ 850
MMEMory:STORe<n>:TRACe.........................................................................................851
[SENSe:]AVERage<n>:COUNt........................................................................................ 851
[SENSe:]AVERage<n>[:STATe<Trace>]........................................................................... 852
[SENSe:]AVERage<n>:TYPE..........................................................................................852
[SENSe:][WINDow:]DETector<trace>[:FUNCtion].............................................................. 853
[SENSe:][WINDow:]DETector<trace>[:FUNCtion]:AUTO.................................................... 853
TRACe<n>:COPY..........................................................................................................854
TRACe<n>:DATA...........................................................................................................854
TRACe<n>[:DATA]:MEMory?.......................................................................................... 855
TRACe<n>[:DATA]:X?.................................................................................................... 856
CALCulate<n>:MATH[:EXPression][:DEFine] <Expression>
This command defines the mathematical expression for relating traces to trace1.
Suffix:
<n>
.
irrelevant
Parameters:
<Expression> (TRACe1-TRACe2) | (TRACe1-TRACe3) | (TRACe1-TRACe4) |
(TRACe1-TRACe5) | (TRACe1-TRACe6)
(TRACe1-TRACe2)
Subtracts trace 2 from trace 1.
(TRACe1-TRACe3)
Subtracts trace 3 from trace 1.
(TRACe1-TRACe4)
Subtracts trace 4 from trace 1.
