Remote Control
R&S
®
ESR
786User Manual 1175.7068.02 ─ 12
Example:
CALC:MARK:X 10MHZ
Sets the reference marker (marker 1) to the carrier signal at 10
MHz.
CALC:MARK:FUNC:MDEP ON
Switches on the modulation depth measurement.
CALC:DELT2:X 10KHZ
Sets delta markers 2 and 3 to the signals at 10 kHz from the car-
rier signal.
CALC:DELT3:X 9.999KHZ
Corrects the position of delta marker 3 relative to delta marker 2.
Manual operation: See "AM Mod Depth" on page 224
See "AM Mod Depth" on page 336
11.5.1.8
Measuring the Harmonic Distortion
The following commands configure and perform measurements to determine the har-
monic distortion of a signal.
Commands useful to retrieve results described elsewhere:
●
TRACe<n>:DATA on page 726
CALCulate<n>:MARKer<m>:FUNCtion:HARMonics:BANDwidth:AUTO...............................786
CALCulate<n>:MARKer<m>:FUNCtion:HARMonics:DISTortion?........................................ 787
CALCulate<n>:MARKer<m>:FUNCtion:HARMonics:LIST?.................................................787
CALCulate<n>:MARKer<m>:FUNCtion:HARMonics:NHARmonics......................................788
CALCulate<n>:MARKer<m>:FUNCtion:HARMonics:PRESet..............................................788
CALCulate<n>:MARKer<m>:FUNCtion:HARMonics[:STATe].............................................. 789
UNIT:THD..................................................................................................................... 789
CALCulate<n>:MARKer<m>:FUNCtion:HARMonics:BANDwidth:AUTO <State>
This command selects the resolution bandwidth of the harmonic in respect to the band-
width of the first harmonic.
For details refer to "Harmonic RBW Auto" on page 341.
Suffix:
<n>
.
Selects the measurement window.
<m> irrelevant
Parameters:
<State> OFF | ON
OFF
identical
ON
a multiple
*RST: ON
Example:
CALC:MARK:FUNC:HARM:BAND:AUTO OFF
Deactivates the automatic bandwidth enlargement.
Remote Commands in Spectrum Analyzer Mode
