R&S ESR Series User Manual

Spectrum Measurements
R&S
®
ESR
369User Manual 1175.7068.02 ─ 12
Filter Bandwidth Filter Type Application
28 MHz CFILter
40 MHz CFILter
6.2.7 Configuring the Sweep Mode – SWEEP Key
The SWEEP key is used to configure the sweep mode. Continuous sweep or single
sweep is possible. The sweep time and the number of measured values are set.
To open the Sweep menu
●
Press the SWEEP key.
The "Sweep" menu is displayed.
Menu and softkey description
●
Chapter 6.2.7.1, "Softkeys of the Sweep Menu", on page 369
Task
●
Chapter 6.2.7.2, "Specifying the Sweep Settings", on page 374
6.2.7.1 Softkeys of the Sweep Menu
The following table shows all softkeys available in the "Sweep" menu. It is possible that
your instrument configuration does not provide all softkeys. If a softkey is only available
with a special option, model or (measurement) mode, this information is provided in the
corresponding softkey description.
Continuous Sweep......................................................................................................370
Single Sweep.............................................................................................................. 370
Continue Single Sweep...............................................................................................370
Sweeptime Manual......................................................................................................370
Sweeptime Auto..........................................................................................................371
Sweep Type................................................................................................................ 371
└ Sweep...........................................................................................................371
└ FFT............................................................................................................... 371
└ Auto...............................................................................................................371
└ FFT Filter Mode............................................................................................ 372
└ Auto.................................................................................................... 372
└ Narrow................................................................................................ 372
Sweep Count...............................................................................................................372
Sweep Points.............................................................................................................. 372
Select Frame...............................................................................................................373
Continue Frame (On Off).............................................................................................373
Frame Count............................................................................................................... 373
Spectrogram Clear......................................................................................................374
