R&S ESR Series User Manual

Spectrum Measurements
R&S
®
ESR
411User Manual 1175.7068.02 ─ 12
Func Activated marker or measurement function
Func.Result Result of the active marker or measurement function
6.3.3.2 Positioning Markers (MKR➙ Key)
The MKR➙ key is used for search functions of measurement markers, assignment of
the marker frequency as center frequency, restriction of the search area and character-
ization of maxima and minima. For details on markers in general, see Chapter 6.3.3.1,
"Controlling Markers", on page 406.
To open the Marker To menu
●
Press the MKR➙ key.
The "Marker To" menu is displayed. If no marker is active, marker 1 will be activa-
ted and a peak search on the trace carried out. Otherwise, the edit dialog box for
the last activated marker is opened and the current frequency/time value is dis-
played.
Menu and softkey description
●
"Softkeys of the Marker To Menu" on page 411
Further information
●
"Effect of Different Peak Excursion Settings (Example)" on page 414
Tasks
●
"Searching for a Maximum" on page 413
●
"Searching for a Minimum" on page 413
●
"Specifying the Search Limits" on page 413
●
"Specifying the Search Range" on page 413
●
"Examining a Signal at the Center in Detail" on page 413
●
"Specifying the Suitable Peak Excursion" on page 414
Softkeys of the Marker To Menu
The following table shows all softkeys available in the "Marker To" menu. It is possible
that your instrument configuration does not provide all softkeys. If a softkey is only
available with a special option, model or (measurement) mode, this information is pro-
vided in the corresponding softkey description.
Functions to position markers decribed elsewhere:
●
"Select Marker (No)" on page 205
●
"Peak" on page 205
●
"Next Peak" on page 205
●
"Marker to Trace" on page 202
●
"Min" on page 205
