To return to selection mode in the diagram

While you are in zoom mode, touching the screen changes the zoom area. In order to

select or move a trace or marker, you must switch back to selection mode:

► Click on the "Selection mode" icon in the toolbar.

To return to original display

► Click on the "Zoom Off" icon in the toolbar.

A dotted rectangle is displayed in the diagram.

Remote commands:

1. Activate the zoom mode:

DISP:ZOOM ON

2. Define the zoom area:

DISP:ZOOM:AREA 5,30,20,100

3. Hide the overview window:

DISP:ZOOM:OVER OFF

3.4.4.7 Adding a Title to the Diagram Header

You can add an introductory title to the trace information in the diagram header.

1. Press the SETUP key.

2. Press the "Display Setup" softkey.

3. Press the "Screen Title On/Off" softkey.

An edit dialog box is displayed.

4. Enter the title and press "ENTER".

The title is displayed at the beginning of the diagram header.

3.4.4.8 Removing the Diagram Footer

Some additional diagram-specific information is displayed in the diagram footer (see

Chapter 3.4.1.4, "Diagram-specific and Trace Information", on page 66). This footer

can be removed from display if necessary.

1. Press the SETUP key.

2. Press the "Display Setup" softkey.

3. Press the "Annotation On/Off" softkey.
