R&S ESR Series User Manual

Remote Control
R&S
®
ESR
708User Manual 1175.7068.02 ─ 12
CALCulate<n>:LIMit<k>:UNIT <Unit>
This command defines the unit of a limit line.
Upon selection of the unit DB the limit line is automatically switched to the relative
mode. For units different from DB the limit line is automatically switched to absolute
mode.
Suffix:
<n>
.
irrelevant
<k> Selects the limit line.
Parameters:
<Unit> DBM | DBPW | WATT | DBUV | DBMV | VOLT | DBUA |
AMPere | DB | DBUV_M | DBUA_M | DEG | RAD | S | HZ |
PCT | (unitless)
If you select dB as the limit line unit, the command automatically
turns the limit line into a relative limit line.
In spectrum mode, units deg, rad, s, Hz and PCT are unavaila-
ble.
*RST: DBM
Example:
CALC:LIM4:UNIT DBUV
Sets the unit of limit line 4 to dBµV.
Configuring Limit Lines
CALCulate<n>:LIMit<k>:CONTrol[:DATA]......................................................................... 709
CALCulate<n>:LIMit<k>:CONTrol:DOMain....................................................................... 709
CALCulate<n>:LIMit<k>:CONTrol:MODE..........................................................................709
CALCulate<n>:LIMit<k>:CONTrol:OFFSet........................................................................710
CALCulate<n>:LIMit<k>:CONTrol:SHIFt...........................................................................710
CALCulate<n>:LIMit<k>:CONTrol:SPACing.......................................................................711
CALCulate<n>:LIMit<k>:LOWer[:DATA]............................................................................711
CALCulate<n>:LIMit<k>:LOWer:MARGin..........................................................................711
CALCulate<n>:LIMit<k>:LOWer:MODE............................................................................712
CALCulate<n>:LIMit<k>:LOWer:OFFSet.......................................................................... 712
CALCulate<n>:LIMit<k>:LOWer:SHIFt............................................................................. 713
CALCulate<n>:LIMit<k>:LOWer:SPACing.........................................................................713
CALCulate<n>:LIMit<k>:LOWer:STATe............................................................................ 713
CALCulate<n>:LIMit<k>:LOWer:THReshold..................................................................... 714
CALCulate<n>:LIMit<k>:UPPer[:DATA]............................................................................ 714
CALCulate<n>:LIMit<k>:UPPer:MARGin.......................................................................... 715
CALCulate<n>:LIMit<k>:UPPer:MODE.............................................................................715
CALCulate<n>:LIMit<k>:UPPer:OFFSet...........................................................................715
CALCulate<n>:LIMit<k>:UPPer:SHIFt.............................................................................. 716
CALCulate<n>:LIMit<k>:UPPer:SPACing......................................................................... 716
CALCulate<n>:LIMit<k>:UPPer:STATe............................................................................. 717
CALCulate<n>:LIMit<k>:UPPer:THReshold...................................................................... 717
Remote Commands in Receiver Mode
