R&S ESR Series User Manual

Remote Control
R&S
®
ESR
843User Manual 1175.7068.02 ─ 12
[SENSe:]SWEep:EGATe:TYPE <Type>
This command sets the type of triggering by the external gate signal.
A delay between applying the gate signal and the start of recording measured values
can be defined, see [SENSe:]SWEep:EGATe:HOLDoff on page 841.
Parameters:
<Type> LEVel | EDGE
LEVel
The gate is level-triggered:
After detection of the gate signal, the gate remains open until the
gate signal disappears. The gate opening time cannot be
defined with the command [SENSe:]SWEep:EGATe:HOLDoff.
Note: Using gating with gate mode "level" and an IFP trigger
(see TRIGger<n>[:SEQuence]:SOURce on page 839), the
holdoff time for the IFP trigger is ignored for frequency sweep,
FFT sweep, zero span and IQ mode measurements.
EDGE
The gate is edge-triggered:
After detection of the set gate signal edge, the gate remains
open until the gate delay ([SENSe:]SWEep:EGATe:HOLDoff)
has expired.
*RST:
EDGE
Example:
SWE:EGAT:TYPE EDGE
Manual operation: See "Gate Mode (Lvl/Edge)" on page 379
11.5.2.6 Vertical Axis Configuration
The following commands configure the characteristics of the vertical diagram axis.
Commands useful to configure the vertical axis described elsewhere:
●
DISPlay[:WINDow<n>]:TRACe<t>:Y:SPACing on page 668
●
INPut:ATTenuation on page 668
●
INPut:COUPling on page 672
●
INPut:GAIN:STATe on page 669
●
INPut:IMPedance on page 670
CALCulate<n>:UNIT:POWer........................................................................................... 844
DISPlay[:WINDow<n>]:TRACe<t>:Y[:SCALe]................................................................... 844
DISPlay[:WINDow<n>]:TRACe<t>:Y[:SCALe]:MODE.........................................................844
DISPlay[:WINDow<n>]:TRACe<t>:Y[:SCALe]:RLEVel........................................................845
DISPlay[:WINDow<n>]:TRACe<t>:Y[:SCALe]:RLEVel:OFFSet........................................... 845
DISPlay[:WINDow<n>]:TRACe<t>:Y[:SCALe]:RPOSition................................................... 846
INPut:ATTenuation:AUTO............................................................................................... 846
UNIT<n>:POWer............................................................................................................846
Remote Commands in Spectrum Analyzer Mode
