Spectrum Measurements
R&S
®
ESR
247User Manual 1175.7068.02 ─ 12
Standard GUI-Parameter SCPI-Parameter
CDMA IS95A forward CDMA IS95A FWD F8CD | FIS95a
CDMA IS95A reverse CDMA IS95A REV R8CD | RIS95a
CDMA IS95C Class 0 forward*) CDMA IS95C Class 0 FWD FIS95c0
CDMA IS95C Class 0 reverse*) CDMA IS95C Class 0 REV RIS95c0
CDMA J-STD008 forward CDMA J-STD008 FWD F19C | FJ008
CDMA J-STD008 reverse CDMA J-STD008 REV R19C | RJ008
CDMA IS95C Class 1 forward*) CDMA IS95C Class 1 FWD FIS95c1
CDMA IS95C Class 1 reverse*) CDMA IS95C Class 1 REV RIS95c1
CDMA 2000 CDMA 2000 S2CD
TD-SCDMA forward TD SCDMA FWD FTCD | TCDMa
TD-SCDMA reverse TD SCDMA REV RTCD
WLAN 802.11A WLAN 802.11A AWLan
WLAN 802.11B WLAN 802.11B BWLan
WiMAX WiMAX WiMAX
WIBRO WIBRO WIBRO
GSM GSM GSM
RFID 14443 RFID 14443 RFID14443
TETRA TETRA TETRA
PDC PDC PDC
PHS PHS PHS
CDPD CDPD CDPD
APCO-25 Phase 2 APCO-25 P2 PAPCo25
For the R&S ESR, the channel spacing is defined as the distance between the center
frequency of the adjacent channel and the center frequency of the transmission chan-
nel. The definition of the adjacent-channel spacing in standards IS95C and CDMA
2000 is different. These standards define the adjacent-channel spacing from the center
of the transmission channel to the closest border of the adjacent channel. This defini-
tion is also used for the R&S ESR if the standards marked with an asterisk *) are
selected.
Optimized Settings for CP/ACLR Test Parameters
The "Adjust Settings" softkey (see "Adjust Settings" on page 243) automatically optimi-
zes all instrument settings for the selected channel configuration, as described in the
following:
●
Frequency span
