R&S ESR Series User Manual

Remote Control
R&S
®
ESR
907User Manual 1175.7068.02 ─ 12
Usage: SCPI confirmed
Manual operation: See "Power Sweep Start" on page 480
SOURce<n>:POWer:STOP <Power>
This command defines the stop power of the power sweep. The stop value can be
smaller than the start value.
Suffix:
<n>
.
1...4
Selects the measurement window.
Parameters:
<Power> Range: -30 dBm to +5 dBm
*RST: 0 dBm
Example:
SOUR:POW:STOP -20dBm
Usage: SCPI confirmed
Manual operation: See "Power Sweep Stop" on page 480
11.7.2 Controlling the External Tracking Generator
[SENSe:]CORRection:TRANsducer:GENerator.................................................................907
SOURce<n>:EXTernal<generator>:FREQuency................................................................908
SOURce<n>:EXTernal<generator>:FREQuency:COUPling[:STATe].................................... 908
SOURce<n>:EXTernal<generator>:FREQuency[:FACTor]:DENominator..............................909
SOURce<n>:EXTernal<generator>:FREQuency[:FACTor]:NUMerator................................. 909
SOURce<n>:EXTernal<generator>:FREQuency:OFFSet<m>.............................................910
SOURce<n>:EXTernal<generator>:FREQuency:SWEep[:STATe]........................................ 911
SOURce<n>:EXTernal<generator>:POWer[:LEVel]............................................................911
SOURce<n>:EXTernal<generator>:ROSCillator[:SOURce].................................................911
SOURce<n>:EXTernal<generator>[:STATe]...................................................................... 912
SYSTem:COMMunicate:GPIB:RDEVice:GENerator<generator>:ADDRess.......................... 913
SYSTem:COMMunicate:RDEVice:GENerator<generator>:INTerface................................... 913
SYSTem:COMMunicate:RDEVice:GENerator<generator>:LINK..........................................913
SYSTem:COMMunicate:RDEVice:GENerator<generator>:TYPE.........................................914
[SENSe:]CORRection:TRANsducer:GENerator <Name>
This command uses the normalized measurement data to generate a transducer factor
with up to 625 points. The trace data is converted to a transducer with unit dB and
stored in a file with the specified name and the suffix.trd under c:\r_s\instr\trd.
The frequency points are allocated in equidistant steps between start and stop fre-
quency. The generated transducer factor can be further adapted using the commands
of the [SENSe<source>:]CORRection:TRANSducer subsystem (see [SENSe:
]CORRection:TRANsducer:DELete on page 952).
This command is only available if the R&S FSV-B10 option (External Tracking Genera-
tor) is installed and normalization is switched on.
Remote Commands to Control the Tracking Generator
