Remote Control
R&S
®
ESR
734User Manual 1175.7068.02 ─ 12
Manual operation: See "# of TX Chan" on page 237
Defining Weighting Filters
The following commands define weighting filters for ACLR measurements.
[SENSe:]POWer:ACHannel:FILTer:ALPHa:ACHannel........................................................ 734
[SENSe:]POWer:ACHannel:FILTer:ALPHa[:ALL]............................................................... 734
[SENSe:]POWer:ACHannel:FILTer:ALPHa:ALTernate<channel>......................................... 734
[SENSe:]POWer:ACHannel:FILTer:ALPHa:CHANnel<channel>.......................................... 735
[SENSe:]POWer:ACHannel:FILTer[:STATe]:ACHannel....................................................... 735
[SENSe:]POWer:ACHannel:FILTer[:STATe]:ALTernate<channel>........................................ 735
[SENSe:]POWer:ACHannel:FILTer[:STATe]:CHANnel<channel>......................................... 735
[SENSe:]POWer:ACHannel:FILTer[:STATe]:ALL................................................................ 736
[SENSe:]POWer:ACHannel:FILTer:ALPHa:ACHannel <Alpha>
This command defines the roll-off factor for the weighting filter of the adjacent channel.
Parameters:
<Alpha> <numeric value>
*RST: 0,22
Example:
POW:ACH:FILT:ALPH:ACH 0,35
Manual operation: See "Weighting Filter" on page 240
[SENSe:]POWer:ACHannel:FILTer:ALPHa[:ALL] <Alpha>
This command defines the roll-off factor for the weighting filter of all channels.
Parameters:
<Alpha> <numeric value>
*RST: 0,22
Example:
POW:ACH:FILT:ALPH:ALL 0,35
[SENSe:]POWer:ACHannel:FILTer:ALPHa:ALTernate<channel> <Alpha>
This command defines the roll-off factor for the weighting filter of the specified alternate
channel.
Suffix:
<channel>
.
1...11
the alternate channel
Parameters:
<Alpha> <numeric value>
*RST: 0,22
Example:
POW:ACH:FILT:ALPH:ALT3 0,35
Sets the alpha value for the weighting filter for the alternate
channel 3 to 0,35.
Remote Commands in Spectrum Analyzer Mode
