Spectrum Measurements
R&S
®
ESR
367User Manual 1175.7068.02 ─ 12
●
Channel filters
For details see Chapter 6.2.6.4, "List of Available RRC and Channel Filters",
on page 367 .
Channel filters do not support FFT mode.
●
RRC filters
For details see Chapter 6.2.6.4, "List of Available RRC and Channel Filters",
on page 367 .
RRC filters do not support FFT mode.
●
5-Pole filters
The available bandwidths are specified in the data sheet.
5-Pole filters do not support FFT mode.
6.2.6.4 List of Available RRC and Channel Filters
For power measurement a number of especially steep-edged channel filters are availa-
ble (see the following table). The indicated filter bandwidth is the 3 dB bandwidth. For
RRC filters, the fixed roll-off factor (a) is also indicated.
Table 6-6: Filter types
Filter Bandwidth Filter Type Application
100 Hz CFILter
200 Hz CFILter
300 Hz CFILter
500 Hz CFILter
1 kHz CFILter
1.5 kHz CFILter
2 kHz CFILter
2.4 kHz CFILter SSB
2.7 kHz CFILter
3 kHz CFILter
3.4 kHz CFILter
4 kHz CFILter DAB, Satellite
4.5 kHz CFILter
5 kHz CFILter
6 kHz CFILter
6 kHz, a=0.2 RRC APCO
7.5 kHz CFILter
8.5 kHz CFILter ETS300 113 (12.5 kHz channels)
9 kHz CFILter AM Radio
