R&S ESR Series User Manual

Remote Control
R&S
®
ESR
659User Manual 1175.7068.02 ─ 12
Using Deltamarkers
Commands useful to work with markers in the spectrogram described elsewhere:
●
CALCulate<n>:DELTamarker<m>:MAXimum:LEFT on page 698
●
CALCulate<n>:DELTamarker<m>:MAXimum:NEXT on page 698
●
CALCulate<n>:DELTamarker<m>:MAXimum[:PEAK] on page 699
●
CALCulate<n>:DELTamarker<m>:MAXimum:RIGHt on page 699
●
CALCulate<n>:DELTamarker<m>:MINimum:LEFT on page 699
●
CALCulate<n>:DELTamarker<m>:MINimum:NEXT on page 700
●
CALCulate<n>:DELTamarker<m>:MINimum[:PEAK] on page 700
●
CALCulate<n>:DELTamarker<m>:MINimum:RIGHt on page 700
Command exclusive to position markers in the spectrogram:
CALCulate<n>:DELTamarker<m>:SGRam:FRAMe............................................................659
CALCulate<n>:DELTamarker<m>:SGRam:SARea............................................................ 660
CALCulate<n>:DELTamarker<m>:SGRam:XY:MAXimum[:PEAK]....................................... 660
CALCulate<n>:DELTamarker<m>:SGRam:XY:MINimum[:PEAK]........................................ 661
CALCulate<n>:DELTamarker<m>:SGRam:Y:MAXimum:ABOVe......................................... 661
CALCulate<n>:DELTamarker<m>:SGRam:Y:MAXimum:BELow..........................................662
CALCulate<n>:DELTamarker<m>:SGRam:Y:MAXimum:NEXT........................................... 662
CALCulate<n>:DELTamarker<m>:SGRam:Y:MAXimum[:PEAK]..........................................662
CALCulate<n>:DELTamarker<m>:SGRam:Y:MINimum:ABOVe.......................................... 663
CALCulate<n>:DELTamarker<m>:SGRam:Y:MINimum:BELow...........................................663
CALCulate<n>:DELTamarker<m>:SGRam:Y:MINimum:NEXT............................................ 664
CALCulate<n>:DELTamarker<m>:SGRam:Y:MINimum[:PEAK]...........................................664
CALCulate<n>:DELTamarker<m>:SGRam:FRAMe <Frame> | <Time>
This command positions the delta marker on a particular frame. The frame is relative to
the position of marker 1.
The command is available for the spectrogram.
Suffix:
<n>
.
1...4
Selects the measurement window.
<m> 1...16
Selects the marker.
Parameters:
<Frame> | <Time> <Frame> (if time stamp is off)
Defines the distance of the deltamarker in frames and in relation
to the position of marker 1.
Note that in receiver mode, it is not possible to select a frame,
only a time.
Remote Commands in Receiver Mode
