Remote Control
R&S
®
ESR
830User Manual 1175.7068.02 ─ 12
Manual operation: See "Auto Freq" on page 357
[SENSe:]ADJust:LEVel
This command automatically sets the optimal reference level for the current measure-
ment.
You can define a threshold that the signal must exceed before the reference level is
adjusted, see [SENSe:]ADJust:CONFiguration:HYSTeresis:UPPer and
[SENSe:]ADJust:CONFiguration:HYSTeresis:LOWer.
Example:
ADJ:LEV
Manual operation: See "Adjust Ref Lvl (span > 0)" on page 292
See "Adjust Ref Lvl (span > 0)" on page 294
See "Auto Level" on page 358
11.5.2.3 Bandwidth Settings
The following commands select the measurement filter bandwidths and characteristics.
Selecting the Resolution Bandwidth
Commands useful to configure the RBW described elsewhere:
●
[SENSe:]BANDwidth|BWIDth[:RESolution] on page 670
●
[SENSe:]BANDwidth|BWIDth[:RESolution]:TYPE on page 671
[SENSe:]BANDwidth|BWIDth[:RESolution]:AUTO..............................................................830
[SENSe:]BANDwidth|BWIDth[:RESolution]:FFT.................................................................831
[SENSe:]BANDwidth|BWIDth[:RESolution]:RATio..............................................................831
[SENSe:]BANDwidth|BWIDth[:RESolution]:AUTO <State>
This command couples and decouples the resolution bandwidth to the span.
The automatic coupling adapts the resolution bandwidth to the current frequency span
according to the relationship between frequency span and resolution bandwidth.
Use [SENSe:]BANDwidth|BWIDth[:RESolution]:RATio to define the ratio
RBW/span.
Parameters:
<State> ON | OFF
*RST: ON
Example:
BAND:AUTO OFF
Switches off the coupling of the resolution bandwidth to the
span.
Manual operation: See "Res BW Manual" on page 361
See "Res BW Auto" on page 361
See "Default Coupling" on page 365
Remote Commands in Spectrum Analyzer Mode
