11.2.8.5 Sharing Directories (only with Microsoft Networks)
Sharing directories makes data available for other users. This is only possible in Micro-
soft networks. Sharing is a property of a file or directory.
1. Press the "Windows" key on the external keyboard or the [CTRL + ESC] key com-
bination on your keyboard to access the operating system.
2. Open the "Windows Explorer".
3. Select the desired folder with the right mouse button.
4. In the context menu, select "Share with > Specific people".
5. Select the users on your network you want to allow access to the directory to.
6. Select "Share" to confirm the settings.
7. Select "Done" to close the dialog box.
The drive is shared and can be accessed by the selected users.
11.3 Selecting the Operating Mode
INSTrument:CREate[:NEW]............................................................................................ 635
INSTrument:DELete....................................................................................................... 636
INSTrument[:SELect]......................................................................................................636
INSTrument:CREate[:NEW] <ChannelType>, <ChannelName>
This command adds an additional spectrum display. You can add up to three additional
spectrum displays.
Also see
●
INSTrument[:SELect] on page 636
●
INSTrument:DELete on page 636
●
Remote program example: Chapter 11.17.16, "Usage of Four Spectrum Instances",
on page 1037
Parameters:
<ChannelType> SANalyzer
The channel type is always SANalyzer to add a new spectrum
display.
<ChannelName> String containing the name of the channel you want to create.
Example:
INST:CRE SAN, 'Spectrum 2'
Adds a second spectrum display.
Selecting the Operating Mode
