R&S ESR Series User Manual

Remote Control
R&S
®
ESR
799User Manual 1175.7068.02 ─ 12
CALCulate<n>:STATistics:SCALe:Y:UPPer <Value>
This command defines the upper limit for the y-axis of the diagram in statistical mea-
surements. Since probabilities are specified on the y-axis, the entered numeric values
are dimensionless.
Suffix:
<n>
.
irrelevant
Parameters:
<Value> 1E-8 to 1.0
*RST: 1.0
Example:
CALC:STAT:SCAL:Y:UPP 0.01
Manual operation: See "y-Axis Max Value" on page 319
11.5.1.12 Measuring in the Time Domain
The following commands configure and perform time domain power measurements.
Configuring the Measurement
The following commands control measurement configurations for measurements of the
time domain power
CALCulate<n>:MARKer<m>:FUNCtion:SUMMary:AOFF................................................... 799
CALCulate<n>:MARKer<m>:FUNCtion:SUMMary:AVERage.............................................. 799
CALCulate<n>:MARKer<m>:FUNCtion:SUMMary:MODE.................................................. 800
CALCulate<n>:MARKer<m>:FUNCtion:SUMMary:PHOLd................................................. 800
CALCulate<n>:MARKer<m>:FUNCtion:SUMMary:REFerence:AUTO ONCE........................801
CALCulate<n>:MARKer<m>:FUNCtion:SUMMary[:STATe].................................................801
CALCulate<n>:MARKer<m>:FUNCtion:SUMMary:AOFF
This command turns all time domain power measurements off.
Suffix:
<n>
.
Selects the measurement window.
<m> Selects the marker.
Example:
CALC:MARK:FUNC:SUMM:AOFF
Switches off the functions for power measurement in zero span.
Usage: Event
CALCulate<n>:MARKer<m>:FUNCtion:SUMMary:AVERage <State>
This command turns averaging for the active power measurement in zero span on and
off.
Averaging is reset by switching it off and on again.
Remote Commands in Spectrum Analyzer Mode
