R&S ESR Series User Manual

Spectrum Measurements
R&S
®
ESR
235User Manual 1175.7068.02 ─ 12
Compatibility to R&S FSP
User standards created on an analyzer of the R&S FSP family are compatible to the
R&S ESR. User standards created on an R&S ESR, however, are not necessarily com-
patible to the analyzers of the R&S FSP family and may not work there.
To store a user-defined configuration
1. Select the "User Standard" softkey in the "Ch Power" menu.
2. Press "Save".
3. Define a file name for the user standard and select its storage location.
By default, the xml file is stored in C:\R_S\Instr\acp_std\. However, you can
define any other storage location.
4. Press "Save".
The following parameter definitions are saved:
● "# of Adj Chan" on page 237
● Channel spacing and adjacent-channel spacing, see "Spacing" on page 239
● Channel bandwidth of transmission (Tx), adjacent (Adj) and alternate (Alt)
channels, see "Bandwidth" on page 238
● Resolution bandwidth, see "Res BW Auto" on page 361
● Video bandwidth, see "Video BW Auto" on page 362
● Detector, see "Detector" on page 391
● ACLR limits and their state, see "Limits" on page 241
● Sweep time and sweep time coupling, see "Sweep Time" on page 243
● Trace and power mode, see "Select Trace" on page 243 and "Power Mode"
on page 242
To load a user-defined configuration
► Press "User Standard > Load" and select the user standard file.
Softkeys for Channel and Adjacent-Channel Power Measurements
Ch Power ACLR..........................................................................................................236
└ CP/ACLR Standard.......................................................................................236
└ CP/ACLR Settings........................................................................................ 237
└ # of TX Chan.......................................................................................237
└ # of Adj Chan......................................................................................237
└ Channel Setup....................................................................................237
└ Bandwidth.................................................................................238
└ ACLR Reference............................................................ 239
└ Spacing.....................................................................................239
└ Names...................................................................................... 240
└ Weighting Filter.........................................................................240
└ Limits........................................................................................ 241
└ Limit Checking................................................................241
└ Relative Limit..................................................................242
└ Absolute Limit.................................................................242
└ Check............................................................................. 242
