Example:
CALC:LIM:ACP:ALT2 30DB, 30DB
Sets the relative limit value for the power in the lower and upper
second alternate adjacent channel to 30 dB below the channel
power.
CALC:LIM:ACP:ALT2:ABS -35DBM, -35DBM
Sets the absolute limit value for the power in the lower and
upper second alternate adjacent channel to -35 dBm.
CALC:LIM:ACP ON
Switches on globally the limit check for the channel/adjacent
channel measurement.
CALC:LIM:ACP:ALT2:STAT ON
Switches on the limit check for the lower and upper second adja-
cent channel.
INIT;*WAI
Starts a new measurement and waits for the sweep end.
CALC:LIM:ACP:ALT2:RES?
Queries the limit check result in the second alternate adjacent
channels.
Usage:
Query only
CALCulate<n>:LIMit<k>:ACPower[:STATe] <State>
This command switches on and off the limit check for adjacent-channel power mea-
surements. The commands CALCulate<n>:LIMit<k>:ACPower:ACHannel[:
RELative]:STATe or CALCulate<n>:LIMit<k>:ACPower:
ALTernate<Channel>[:RELative]:STATe must be used in addition to specify
whether the limit check is to be performed for the upper/lower adjacent channel or for
the alternate adjacent channels.
Suffix:
<n>
.
Selects the measurement window.
<k> irrelevant
Parameters:
<State> ON | OFF
*RST: OFF
Example:
CALC:LIM:ACP ON
Switches on the ACLR limit check.
Manual operation: See "Limit Checking" on page 241
See "Relative Limit" on page 242
See "Absolute Limit" on page 242
Analyzing Results
The following commands analyze and retrieve measurement results for ACLR mea-
surements.
Remote Commands in Spectrum Analyzer Mode

R&S ESR Series Specifications
