Siemens SINAMICS S120 User Manual

Line connection and line-side power components
3.9 Active Interface Modules internal air cooling
Booksize Power Units
134 Manual, (GH2), 07/2016, 6SL3097-4AC00-0BP8
Table 3- 26 Electrical test on the 16 kW Active Interface Module
Active Interface Module 16 kW
RIGHT
: Measurement with original
terminal connectors
WRONG
: Measurement via the device
sockets
3.9.9
Technical data
Table 3- 27 Technical data
Active Interface Module
6SL3100-
0BE21-6AB.
0BE23-6AB.
0BE25-5AB.
0BE28-0AB.
0BE31-2AB.
16 kW
36 kW
55 kW
80 kW
120 kW
P
max
kW
35
70
110
131
175
I
rated
A
26
58
88
128
192
I
max
A
59
117
176
218
292
Current requirement of
the
24 VDC electronics
power supply
A 0.25 0.49 0.6 1.2 1.2
Line voltage
V
3-phase 380°V°...°480°VAC ±°10%
Line frequency
Hz
47 … 63
Cooling air requirement m
3
/h 112 160 300 600 600
Power loss
1)
(see power
loss tables (Page 756))
W 270 340 380 490 585
Weight
kg
11.6
19.0
23.2
31.9
36.6
Connection cross-
section
mm
2
10 35 50 120 120
PE connecting studs
M5
M6
M6
M8
M8
1)
Referred to U
DC link
= 600 V
