Siemens SINAMICS S120 User Manual

Cabinet design and EMC Booksize
12.7 Connection systems
Booksize Power Units
714 Manual, (GH2), 07/2016, 6SL3097-4AC00-0BP8
12.7.3
Current-carrying capacity and derating factors for power cables and signal
cables
The current carrying capacity of PVC/PUR-insulated copper cables is specified for routing
types B1, B2 and C under continuous operating conditions in the table below with reference
to an ambient air temperature of 40° C. For other ambient temperatures, the values must be
corrected by the factors listed in the "Derating factors for deviating ambient temperatures"
table.
Table 12- 17
Routing types
B1
Cables in conduits or cable ducts
B2
Multi-conductor cables in conduits or cable ducts
C
Cables along walls, without conduits or cable ducts
Table 12- 18 Current carrying capacity according to EN 60204-1 for 40° C ambient temperature
Cross-section
Current carrying capacity, effective; AC 50/60 Hz or DC
For routing type
mm
2
B1
A
B2
A
C
A
Signal cables
0.20
–
4.3
4.4
0.50
–
7.5
7.5
0.75
–
9
9.5
Power cables
0.75
8.6
8.5
9.8
1.00
10.3
10.1
11.7
1.50
13.5
13.1
15.2
2.50
18.3
17.4
21
4
24
23
28
6
31
30
36
10
44
40
50
16
59
54
66
25
77
70
84
35
96
86
104
50
117
103
125
70
149
130
160
95
180
165
194
120
208
179
225
