Line Modules Booksize
4.9 Smart Line Modules with internal air cooling
Booksize Power Units
278 Manual, (GH2), 07/2016, 6SL3097-4AC00-0BP8
Figure 4-68 Dimension drawing of 5 kW and 10 kW Smart Line Modules with internal air cooling, all
dimensions in mm and (inches)
Note
The shield connecting plate is integrated in the line connector of the 50 mm Smart Line
Modules.
