Siemens SINAMICS S120 User Manual

Cabinet design and EMC Booksize
12.12 Power losses of the components
Booksize Power Units
Manual, (GH2), 07/2016, 6SL3097-4AC00-0BP8
761
12.12.6
Power loss for power units with cold plate
With cold-plate cooling, only part of the power loss remains in the cabinet.
The table below shows the internal and external power loss of the components.
Table 12- 38 Overview of power loss at rated operation for power units with cold plate (including electronics losses)
Unit
Internal power loss
1)
External power loss
Total power loss
Active Line Modules
16 kW W 70.4 (50 + 20.4) 210 280.4
36 kW
W
135.2 (110 + 25.2)
520
655.2
55 kW W 187.6 (160 + 27.6) 740 927.6
80 kW
W
283.6 (250 + 33.6)
1100
1383.6
120 kW
W
443.2 (400 + 43.2)
1800
2243.2
Smart Line Modules Booksize
5 kW
W
34.4 (20 + 14.4)
40
74.4
10 kW
W
56.8 (40 + 16.8)
80
136.8
Smart Line Modules Booksize Compact
16 kW
W
56.6 (36.2 + 20.4)
130
186.6
Basic Line Modules
20 kW
W
46.6 (25 + 21.6)
95
141.6
40 kW
W
71.4 (45 + 26.4)
205
276.4
100 kW
W
168.4 (130 + 38.4)
450
618.4
Single Motor Modules Booksize
3 A
W
27.6 (12 + 15.6)
18
45.6
5 A
W
35.6 (20 + 15.6)
35
70.6
9 A
W
45.6 (30 + 15.6)
50
95.6
18 A
W
80.6 (65 + 15.6)
100
180.6
30 A W 85.6 (70 + 15.6) 220 305.6
45 A
W
108 (90 + 18.0)
340
448
60 A
W
128 (110 + 18.0)
480
608
85 A
W
149.2 (130 + 19.2)
620
769.2
132 A
W
220.4 (200 + 20.4)
1050
1270.4
200 A
W
370.4 (350 + 20.4)
1700
2070.4
Single Motor Modules Booksize Compact
3 A
W
25.6 (10 + 15.6)
40
65.6
5 A
W
30.6 (15 + 15.6)
65
95.6
9 A
W
45.6 (30 + 15.6)
50
95.6
18 A
W
80.6 (65 + 15.6)
100
180.6
Double Motor Modules Booksize
2x3 A
W
55.6 (34 + 21.6)
36
91.6
2x5 A
W
61.6 (40 + 21.6)
65
126.6
2x9 A
W
81.6 (60 + 21.6)
100
181.6
2x18 A
W
95.2 (70 + 25.2)
250
345.2
