Siemens SINAMICS S120 User Manual

Line Modules Booksize
4.3 Active Line Modules with internal air cooling
Booksize Power Units
168 Manual, (GH2), 07/2016, 6SL3097-4AC00-0BP8
4.3.7
Technical data
Table 4- 10 Technical data for Active Line Modules with internal air cooling, part 1
Internal air cooling
6SL3130–
7TE21–6AA.
7TE23–6AA.
7TE25–5AA.
7TE25–5AA3 +
Active Interface
Module
Rated power
kW
16
36
55
55
Infeed
1)
Rated power S1 duty
Infeed power S6 duty (40 %)
Peak infeed power
kW (P
n
)
kW (P
S6
)
kW (P
max
)
16
21
35
36
47
70
55
71
91
55
71
110
Regenerative feedback
Continuous regenerative power
Peak regenerative power
kW
kW
16
35
36
70
55
91
55
110
Supply voltages
Line voltage
Line frequency
Electronics power supply
V
ACrms
Hz
V
DC
3 AC 380 … 480 ± 10 % (-15 % < 1 min)
47 … 63
24 (20.4 … 28.8)
DC link voltage
Overvoltage trip
Undervoltage trip
2)
V
DC
V
DC
V
DC
510 … 720
820 ± 2 %
360 ± 2 %
Input currents
Rated input current:
for AC 400 V
input current:
for AC 380 V / AC 480 V
for AC 400 V; S6 duty (40 %)
for AC 400 V; peak current
A
AC
A
AC
A
AC
A
AC
25
26 / 21
32
54
55
58 / 46
71
107
84
88 / 70
108
139
84
88 / 70
108
168
DC link currents
Rated DC link current:
for 600 V
DC link current:
for 600 V DC; S6 duty (40 %)
for 600 V DC; peak current
A
DC
A
DC
A
DC
27
35
59
60
79
117
92
121
152
92
121
176
Current carrying capacity
DC link busbars
Reinforced DC link busbars
24 V DC busbars
A
DC
A
DC
A
DC
100
150
20
200
--
20
200
--
20
200
--
20
Electronics current drawn
at 24 V DC
A
DC
0.95
1.5
1.9
1.9
Total power loss
(including electronics losses, see
Power loss tables (Page 756))
W 282.8 666 945.6 945.6
DC link capacitance
Active Line Module
Drive line-up, max.
μF
μF
705
20000
1410
20000
1880
20000
1880
20000
Power factor
cos φ
1
1
1
1
Circuit breaker
(IEC 60947 and UL)
See Chapter Overcurrent protection using fuses and circuit breakers
(Page 51)
