Cabinet design and EMC Booksize
12.7 Connection systems
Booksize Power Units
720 Manual, (GH2), 07/2016, 6SL3097-4AC00-0BP8
Motor connection connector
Motor Modules 3 A to 30 A are supplied without a motor plug connector (power connector).
Prefabricated MOTION-CONNECT power cables with pre-assembled motor connectors or
unassembled power cables can be used to connect motors.
The motor plug connector must be ordered separately for power cables that do not have
preassembled connectors (screw connector with article number 6SL3162-2MA00-0AA0).
The motor connector is equipped with a locking mechanism. Mounting on the Motor Module
is described in the following.
Mounting on the Motor Module
Motor connectors with locking mechanism are available in two versions:
● Crimp plug for pre-assembled motor cables
● Screw connector for motor cables that need to be assembled
The way in which motor connectors are installed depends on the type of Motor Module used.
Note
With Double Motor Modules, the rear motor connector must be installed first and then
locked
.
