Siemens SINAMICS S120 User Manual

Line connection and line-side power components
3.7 Line filters
Booksize Power Units
78 Manual, (GH2), 07/2016, 6SL3097-4AC00-0BP8
Line/load connection
Table 3- 9 Line and load connection, Basic Line Filter for Basic Line Modules
6SL3000-
0BE21-6DA.
0BE23-6DA1
0BE31-2DA.
Rated power [kW]
20
40
100
Line supply connection
L1, L2, L3
Screw terminals
10 mm
2
, 3 pole
1.5 ... 1.8 Nm
Screw terminals
35 mm
2
, 3 pole
3.2 ... 3.7 Nm
Screw terminals
95 mm
2
, 3-pole
15 ... 20 Nm
Load connection
L1´, L2´, L3´
PE connection
1)
Terminal studs
M6 / 6 Nm
Terminal studs
M6 / 6 Nm
Terminal studs
M10 / 10 Nm
1)
For ring cable lugs without insulation (Page 732)
3.7.5.3
Dimension drawings
Figure 3-17 Dimension drawing of Basic Line Filter for Basic Line Modules 20 kW, all data in mm and (inches)
