Line Modules Booksize
4.9 Smart Line Modules with internal air cooling
Booksize Power Units
262 Manual, (GH2), 07/2016, 6SL3097-4AC00-0BP8
Additional safety instructions for Smart Line Modules Booksize
Destruction of the Smart Line Module for an incorrect switch-on or switch-off sequence
It is essential that an appropriate switch-on and switch-of sequence (Page 263) is complied
with in order to control the 5 kW and 10 kW Smart Line Modules; if this sequence is not
observed, the Smart Line Module could be damaged beyond repair.
• Comply with the specified switching sequence.
Note
Connected to the public low-voltage network
Smart Line Modules have been designed for use in the industrial environment and generate
current harmonics on the line side as a result of the rectifier circuit.
When connecting a machine with integrated Smart Line Modules to the public low
-voltage
pply (grid), authorization is required in advance from the local power supply company
(utility company) in the following cases:
The rated current of the motor ≤ 16 A per conductor.
The rated motor current does not comply with the requirements specified in EN 61000-3-
2 regarding current harmonics.
