Siemens SINAMICS S120 User Manual

Cabinet design and EMC Booksize
12.12 Power losses of the components
Booksize Power Units
760 Manual, (GH2), 07/2016, 6SL3097-4AC00-0BP8
12.12.5
Power loss for power units with external air cooling
Table 12- 37 Overview of power loss at rated operation for power units with external air cooling (including electronics
losses)
Unit
Internal
Power loss
1)
External power loss
Total power loss
Active Line Modules
16 kW W 82.8 (60 + 22.8) 200 282.8
36 kW
W
171 (135 + 36.0)
495
666
55 kW
W
245.6 (200 + 45.6)
700
945.6
80 kW
W
338.6 (305 + 33.6)
1045
1383.6
120 kW
W
533.2 (490 + 43.2)
1710
2243.2
Smart Line Modules
5 kW
W
41.2 (22 + 19.2)
38
79.2
10 kW
W
66.6 (45 + 21.6)
75
141.6
16 kW
W
64.8 (42 + 22.8)
123
187.8
36 kW
W
116 (80 + 36)
290
406
55 kW
W
185.6 (140 + 45.6)
480
665.6
Single Motor Modules
3 A
W
35.4 (15 + 20.4)
15
50.4
5 A
W
43.4 (23 + 20.4)
30
73.4
9 A
W
55.4 (35 + 20.4)
45
100.4
18 A
W
95.4 (75 + 20.4)
90
185.4
30 A
W
99.2 (80 + 19.2)
210
309.2
45 A
W
135.2 (110 + 25.2)
320
455.2
60 A
W
160.2 (135 + 25.2)
455
615.2
85 A W 196 (160 + 36.0) 590 786
132 A
W
270.4 (250 + 20.4)
1000
1270.4
200 A
W
455.4 (435 + 20.4)
1615
2070.4
Double Motor Modules
3 A
W
62.6 (35 + 27.6)
35
97.6
5 A
W
72.6 (45 + 27.6)
60
132.6
9 A
W
92.6 (65 + 27.6)
95
187.6
18 A
W
111.2 (80 + 31.2)
240
351.2
1)
Power loss of the power electronics + power loss of the 24 V electronics
