Siemens SINAMICS S120 User Manual

Cabinet design and EMC Booksize
12.12 Power losses of the components
Booksize Power Units
Manual, (GH2), 07/2016, 6SL3097-4AC00-0BP8
763
12.12.8
Electronics losses of power units
Table 12- 40 Electronics losses for power units with internal/external air cooling
Component
Internal/external air cooling
Power loss [W]
Single Motor Modules
3 A
20.4
5 A 20.4
9 A
20.4
18 A 20.4
30 A
19.2
45 A
25.2
60 A
25.2
85 A
36.0
132 A
20.4
200 A
20.4
Single Motor Modules Booksize Com-
pact
3 A
20.4
5 A
20.4
9 A
20.4
18 A
20.4
Double Motor Modules
3 A
27.6
5 A
27.6
9 A
27.6
18 A
31.2
Double Motor Modules Booksize Com-
pact
1.7 A
27.6
3 A
27.6
5 A 27.6
Active Line Modules
16 kW
22.8
36 kW
36.0
55 kW
45.6
80 kW
33.6
120 kW
43.2
Basic Line Modules 20 kW 24
40 kW
33.6
100 kW
48
Smart Line Module
5 kW
19.2
10 kW
21.6
16 kW
22.8
36 kW
36.0
55 kW
45.6
Smart Line Module Booksize Compact
16 kW
22.8
