Siemens SINAMICS S120 User Manual

Accessories
11.6 DRIVE-CLiQ cabinet bushings
Booksize Power Units
652 Manual, (GH2), 07/2016, 6SL3097-4AC00-0BP8
11.5.7
Technical specifications
Table 11- 25 Technical data DC link adapter
6SL3162-
Unit
2BM01-0AA0
2BM10-0AA0
Current-carrying capacity
– attached using 2 screws
– attached using 4 screws
A
A
150
240
150
---
Connection cross-section mm² 35 … 95 35 … 95
Stripped length
mm
27
27
Tightening torque
– terminals
– DC link busbars
Nm
Nm
13
1.8
13
1.8
Weight
kg
0.34
0.33
11.6
DRIVE-CLiQ cabinet bushings
11.6.1
Description
A DRIVE-CLiQ cabinet bushing is used to connect the DRIVE-CLiQ cables between the
inside and outside of the control cabinet. It is used in a control cabinet panel. The data lines
and the voltage supply contacts of the DRIVE-CLiQ are also routed through the bushing. The
DRIVE-CLiQ cabinet bushing for DRIVE-CLiQ cables is available with DRIVE-CLiQ
connector and M12 connector/socket.
DRIVE-CLiQ cabinet bushing for DRIVE-CLiQ connectors
The cabinet bushing has degree of protection IP54 according to IEC 60529 from the outside
towards the inside. Inside the control cabinet, a connection is established according to
degree of protection IP20 or IPXXB acc. to IEC 60529. So that the complete outside of the
cabinet bushing, including the DRIVE-CLiQ interface, has degree of protection IP54, a
DRIVE-CLiQ cable must be used, which as a minimum must also have degree of protection
IP54.
DRIVE-CLiQ cabinet bushing for M12 connector/socket
The cabinet bushing has degree of protection IP67 according to IEC 60529 from the outside
towards the inside. Inside the cabinet a connection according to degree of protection IP67 in
compliance with IEC 60529 is realized.
