Page #536 background image
DC link components
8.6 Control Supply Module CSM
Booksize Power Units
536 Manual, (GH2), 07/2016, 6SL3097-4AC00-0BP8
8.6.4
Connection examples
The Control Supply Module is connected to the line supply (3-ph. 380 V AC -10 % to 480 V
AC +10 %) via interface X1 (screw terminals 0.2 to 4 mm
2
). This connection should
preferably be made without using an isolating device (e.g. contactor).
The Control Supply Module has an internal line filter (Class A for TN systems), and the pre-
charging circuit for the DC link inside the device is electrically isolated from the 24 V supply.
The Control Supply Module also features a current limitation function.
Note
If you use cables with a cross
-section of 2.5 mm
2
, no additional protection is required on the
24 V side
for the following cable types:
•
Cables of the XLPE type
•
Cables of the EPR type
•
Cable with a similar properties and which is thermally stable up to 90 °C
Note
Observe the connection sequence
If a selectively tripping, AC/DC
-sensitive RCCB is used for the drive line-up, the Control
Supply Module must always be connected to the line supply downstream of this circuit
breaker. Otherwise, the residual current operated circuit breaker will trip erroneously if the
direct
-current component is asymmetrically drawn in certain operating states.
