Siemens SINAMICS S120 User Manual

Motor-side power components
10.2 Voltage Protection Module VPM
Booksize Power Units
590 Manual, (GH2), 07/2016, 6SL3097-4AC00-0BP8
10.2.8
Technical data
Table 10- 15 Technical data
VPM 120
VPM 200
VPM 200 Dynamic
Article No.
6SN1113-1AA00-1JA.
6SN1113-1AA00-1KA.
6SN1113-1AA00-1KC.
Type of voltage 3-phase pulsed AC voltage, motor EMF
Ramp-up time for VPM
1 s (from pulse enable)
Normal range of the
DC link voltage:
- lower limit
- upper limit
490 V DC
795 V DC
Operating range for VPM
830 … 2000 V (peak value)
Motor EMF
< 1.4 kV
rms
Clock frequency
3.2 ... 8 kHz
Rated current
120 A
rms
200 A
rms
Time range
Maximum permissible short-circuit current
0 ... 10 ms
10 ... 500 ms
500 ms ... 2 min
> 2 min
1500 A
255 A
90 A
0 A
2000 A
600 A
200 A
0 A
Max. perm. short-circuit time
120 s
Safe electrical separation
Between the signal contact and motor cables U, V, W, UL 508 C
Permitted humidity
Humidity classification accord-
ing to
EN 60721-3-3
< 90 %
Cl. 3K5, condensation and icing excluded
Low air temperature 0 °C
Permissible ambient tempera-
ture
0 … 55 °C
Cooling method Air-cooled, free convection
Weight
Approx. 6 kg
Approx. 11 kg
Approx. 13 kg
Dimensions (H x W x D) [mm]
300 x 150 x 180
300 x 250 x 190
300 x 250 x 260
