Siemens SINAMICS S120 User Manual

Cabinet design and EMC Booksize
12.7 Connection systems
Booksize Power Units
732 Manual, (GH2), 07/2016, 6SL3097-4AC00-0BP8
12.7.9
Cable lugs
Figure 12-36 Dimension drawing of cable lugs
Table 12- 30 Dimensions of cable lugs
Screw/bolt
Cable cross-section
[mm
2
]
a
[mm]
c
[mm]
d
1
[mm]
d
2
[mm]
d
3
[mm]
l
[mm]
r
[mm]
s
[mm]
M5
1 - 2.5
5
4.5
2.3
5.3
10
14
6.5
0.8
M5
2.5 - 6
6
6
3.6
5.3
10
15
6.5
1
M5
6 - 10
8
8
4.5
5.3
10
16
6.5
1.1
M5
10 - 16
10
10.5
5.8
5.3
11
20
7.5
1.2
M6
2.5 - 6
6
6
3.6
6.5
11
16
7.5
1
M6
6 - 10
8
8
4.5
6.5
11
17
7.5
1.1
M6
10 - 16
10
10.5
5.8
6.5
11
20
7.5
1.2
M6
16 - 25
11
12
7.5
6.5
12
25
7.5
1.5
M6
25 - 35
12
15
9
6.5
15
26
9.5
1.6
M6
35 - 50
16
17
11
6.5
15
26
9.5
1.6
M6
50 - 70
18
21
13
6.5
22
38
12
2
M8
10 - 16
10
10.5
5.8
8.4
14
22
10
1.2
M8
16- 25
11
12
7.5
8.4
16
25
10
1.5
M8
25 - 35
12
15
9
8.4
16
26
10
1.6
M8
35 - 50
16
17
11
8.4
18
34
10
1.8
M8
50 - 70
18
21
13
8.4
22
38
12
2
M8
70 - 95
20
23
15
8.4
24
42
12
2.5
M8
95 - 120
22
24
16.5
8.4
24
44
12
3
M10
35 -
50
16 17 11 10.5 18 34 12 1.8
