4.4 Active Line Modules with external air cooling
Booksize Power Units
190 Manual, (GH2), 07/2016, 6SL3097-4AC00-0BP8
Note
If the cooling air requirement is not covered by the filtered fan, the components cannot
output their specified power.
The filters with filter fan must be regularly check
ed for dirt and cleaned if necessary.
4.4.7
Technical data
Table 4- 22 Technical data for Active Line Modules with external air cooling, part 1
External air cooling
6SL3131-
7TE21-6AA.
7TE23-6AA.
7TE25-5AA.
7TE25-5AA3 +
Active Inter-
face Module
Rated power
kW
16
36
55
55
Infeed
1)
Rated power S1 duty
Infeed power S6 duty (40 %)
Peak infeed power
kW (P
n
)
kW (P
S6
)
kW (P
max
)
16
21
35
36
47
70
55
71
91
55
71
110
Regenerative feedback
Continuous regenerative power
Peak regenerative power
kW
kW
16
35
36
70
55
91
55
110
Supply voltages
Line voltage
Line frequency
Electronics power supply
V
ACrms
Hz
V
DC
3 AC 380 … 480 ± 10 % (15 % < 1 min)
47 … 63 Hz
24 (20.4 … 28.8)
DC link voltage
Overvoltage trip
Undervoltage trip
2)
V
DC
V
DC
V
DC
510 … 720
820 ± 2 %
360 ± 2 %
Input currents
Rated input current:
for AC 400 V
input current:
for AC 380 V / AC 480 V
for AC 400 V; S6 duty (40 %)
for AC 400 V; peak current
A
AC
A
AC
A
AC
A
AC
25
26 / 21
32
54
55
58 /46
71
107
84
88 / 70
108
139
84
88 /70
108
168
DC link currents
Rated DC link current:
for 600 V
DC link current:
for 600 V DC; S6 duty (40 %)
for 600 V DC; peak current
A
DC
A
DC
A
DC
27
35
59
60
79
117
92
121
152
92
121
176
Current carrying capacity
DC link busbars
Reinforced DC link busbars
24 V DC busbars
A
DC
A
DC
A
DC
100
150
20
200
--
20
200
--
20
200
--
20
Electronics current drawn
at 24 V DC
A
DC
0.95
1.5
1.9
1.9
