4.8 Basic Line Modules with cold plate
Booksize Power Units
258 Manual, (GH2), 07/2016, 6SL3097-4AC00-0BP8
1. Remove the connection bracket to
the noise suppression capacitor using a
Tx25 screwdriver.
2. Withdraw the connection bracket. 3. Connection bracket to the interfer-
ence suppression capacitor
Note
Installing the connection bracket for the interference-suppression capacitor
For operation in other line supplies, the connection bracket must be reinstalled and fixed with
a tightening torque of 1.8 Nm.
4.8.8
Technical data
Table 4- 62 Technical data for Basic Line Modules with cold plate cooling
6SL3136-
1TE22-0AA0
1TE24-0AA0
1TE31-0AA0
Rated power
kW
20
40
100
Infeed
1)
Rated power S1 duty
Infeed power S6 duty (40 %)
Peak infeed power
kW (P
n
)
kW (P
S6
)
kW (P
max
)
20
26
60
40
52
120
100
130
175
Braking power
Continuous power
Peak power
kW (P
n
)
kW (P
max
)
5
40
10
80
-
-
Supply voltages
Line voltage
Line frequency
Electronics power supply
V
ACrms
Hz
V
DC
3 AC 380 … 480 ± 10 % (-15 % < 1 min)
47 … 63
24 (20.4 … 28.8)
DC link voltage
Overvoltage trip
Undervoltage trip
2)
V
DC
V
DC
V
DC
510 … 720
820 ± 2 %
360 ± 2 %
